iConverter Modular T1/E1

The iConverter Modular T1/E1 Multiplexer transports up to sixteen T1/E1 circuits and 10/100/1000 Ethernet over point[1]to-point 1000Mbps fiber, CWDM/DWDM channel or Ethernet Virtual Connection (EVC).

This flexible and scalable system is comprised of an iConverter Fiber Transport module, and one or more iConverter 4xT1/E1 MUX modules installed in a 2, 5 or 19-module chassis.

Each iConverter Fiber Transport module and up to four contiguous iConverter 4xT1/E1 MUX modules combine to form a MUX group. A MUX group connects with another MUX group at the opposite end of a dedicated fiber link or EVC. A MUX group can also interoperate with a Managed iConverter fixed-configuration T1/E1 Multiplexer.


iConverter_Modular_T1-E1_MUX.pdf
PDF-Dokument [938.9 KB]

iConverter T1/E1 MUX/M

The iConverter T1/E1 MUX/M multiplexes up to sixteen T1 or E1 circuits and one 10/100/1000 Ethernet service onto a 1000Mbps fiber optic transport link, and features remote management testing and configuration capabilities.

The iConverter T1/E1 MUX/M operates in a back-to-back configuration, and can be used in applications such as multiple T1/E1 extension, mobile backhaul and building-to-building PBX connectivity.

The T1/E1 copper interfaces are available in 4, 8, 12 or 16 RJ-48 port configurations for balanced T1/E1 applications. Optional adapter cables are available to convert each RJ-48 interface to a BNC interface for unbalanced E1 transport applications.


iConverter_T1-E1_MUX-M.pdf
PDF-Dokument [562.1 KB]

iConverter 4xT1/E1 MUX

The iConverter 4xT1/E1 MUX multiplexs up to four T1/E1s and an optional 10/100 Ethernet onto a fiber optic transport link.

The unmanaged T1/E1 Multiplexer provides an easy-to-use and cost-effective multi-service solution for providing TDM and Ethernet connectivity.

The iConverter 4xT1/E1 MUXes operate in a back-to-back configuration, with one multiplexer at each end of the fiber link. The 4xT1/E1 MUX transports services from legacy TDM equipment across long distances that exceed the reach or capacity of copper. This includes applications such as T1/E1 extension, mobile backhaul and building-to-building PBX connectivity, making it ideal for Enterprise, Telecom and Utility industries.



iConverter_4xT1-E1_MUX.pdf
PDF-Dokument [624.8 KB]

iConverter 4xT1/E1 MUX/M

The iConverter 4xT1/E1 MUX/M multiplexes up to four T1/E1s and Ethernet onto a 1000Mbps fiber optic transport link, and features remote management testing and configuration capabilities.

The iConverter 4xT1/E1 MUX/M operates in a back-to-back configuration, with one multiplexer at each end of the fiber transport link. The 4xT1/E1 MUX/M can be used in applications where services from legacy TDM equipment require transport across long distances that exceed the reach or capacity of copper. This includes applications such as T1/E1 extension, mobile backhaul and building-to-building PBX connectivity, making it ideal for Enterprise, Telecom and Utility industries.


iConverter_4xT1-E1_MUX-M.pdf
PDF-Dokument [723.6 KB]
