VLAN-Switch, Ethernet-LWL-Konverter und Netzschnittstellen- gerät 1000X zu 1000X-LWL mit integriertem Management und erweiterten Merkmalen
Der iConverter 2GXM2 entspricht den EFM-LWL-Standards (Ethernet in the First Mile) zur Unterstützung von Fiber-to-the-X-Metropolitan- und lokalen Unternehmensnetzen. Der 2GXM2 bietet eine intelligente, sicher verwaltete Netzabgrenzung im Haus des Kunden mit Quality of Service (QoS) und verbesserter Bandbreitenüberwachung (Ratenkontrolle). Der 2GXM2 verfügt über einge-bautes OAM (Operation, Administration and Maintenance) mit umfassender Leistungsüberwachung, Fehler-erkennung und Dienstebereitstellung.
10Gbps Protocol-Transparent Media Converter/
Transponder
The iConverter XG and XG+ is a 10 Gigabit, protocol-transparent media converter with two pluggable transceiver ports, supporting any combination of XFP and SFP+ transceivers. The unmanaged iConverter XG standalone converter supports 100% traffic throughput with no packet size restrictions. It can function as copper-to-fiber converter, a fiber mode converter, a WDM transponder or a fiber repeater.
The iConverter XG and XG+ are protocol-transparent fiber converters/transponders with automatic speed selection of data rates from 6Gbps to 11.32Gbps.
The XG+ features pluggable transceiver ports, and can be used as a fiber mode converter, a CWDM or DWDM transponder, or a fiber repeater supporting the three Rs (regeneration, retiming and reshaping).
The iConverter XG+ supports 10G Ethernet, 10G SONET/ SDH, 10G Fibre Channel, 10G OTN (G.709)
and CPRI rates up to option 8 (6 Gbps to 11.32 Gbps).
The iConverter xFF is a protocol-transparent media converter, and is available as a
compact, unmanaged standalone unit or a managed chassis plug-in module.
The iConverter xFF is a Optical-Electrical-Optical (OEO) device, and provides reliable and cost-effective conversion between different wavelengths, multimode and single-mode, and dual and
single-fiber.
The iConverter xFF operates as a protocol and rate-transparent device, supporting Small Form
Pluggable (SFP) transceivers with constant data rates from 1Mbps to 8.50Gbps. The xFF supports a variety of network applications, including T1/E1, T3/E3, Ethernet, Fast Ethernet, Gigabit Ethernet,
SONET (OC-3/12/48), SDH (STM-1/4/16), 1x/2x/4x/8x Fibre Channel and Common Public Radio Interface (CPRI).
The iConverter xFF is an industrial protocol-transparent media converter and
transponder that is available as a compact, unmanaged standalone unit or a managed chassis plug-in module.
The iConverter xFF provides reliable and cost-effective conversion between different wavelengths, multimode and single-mode, and dual and single-fiber.
The iConverter xFF operates as a protocol and rate[1]transparent device, supporting Small Form Pluggable (SFP) transceivers with data rates from 1Mbps to 8.50Gbps. The xFF supports a variety of network protocols, including
Ethernet, Fast Ethernet, Gigabit Ethernet, SONET (OC-3/12/48), SDH (STM-1/4/16), 1x/2x/4x/8x Fibre Channel and Common Public Radio Interface (CPRI).
The iConverter GX/X managed fiber-to-fiber Gigabit Ethernet fiber converter/transponder is a member of the modular iConverter product family. The GX/X provides a cost-effective solution to extend fiber network distances.
The GX/X also functions as a fiber repeater supporting the three Rs (regeneration, retiming and reshaping). Multiple GX/X modules can be cascaded to extend total network distances.
iConverter GX/X models support multimode and single-mode dual fiber with SC and LC connectors; and single-mode single-fiber with SC connectors.
The iConverter GX/X features two 10/100 Ethernet backplane ports to provide connectivity to adjacent modules for network expansion and for in-band connectivity to an iConverter Network Management Module.
The iConverter GX/X advanced features include IEEE 802.1Q VLAN, 802.1p Quality of Service prioritization and Port Access Control, which provides the ability to enable or disable individual ports to control delivery of services. The GX/X also supports port-level MIB statistics reporting real-time packet statistics, performance and operational monitoring.
The iConverter GX/F managed fiber-to-fiber Gigabit to Fast Ethernet converter/transponder is a member of the modular iConverter product family.
The GX/F provides fiber and rate conversion between Gigabit Ethernet fiber and Fast Ethernet fiber, enabling seamless integration between Gigabit Ethernet and legacy Fast Ethernet networks.
The GX/F also functions as a fiber repeater supporting the three Rs (regeneration, retiming and reshaping). Multiple GX/F modules can be cascaded to extend total network distances.
iConverter GX/F models support multimode and single-mode dual fiber with SC and LC connectors; and single-mode single-fiber with SC connectors.
The iConverter GX/F features two 10/100 Ethernet backplane ports to provide connectivity to adjacent modules for network expansion and for in-band connectivity to an iConverter Network Management Module.
The iConverter 1000FF is a Gigabit Ethernet fiber-to-fiber converter/transponder available as a compact, unmanaged standalone unit or a managed chassis plug-in module.
The iConverter 1000FF provides a cost-effective solution to extend fiber network distances with multimode to single-mode, dual fiber to single-fiber, and wavelength (850/1310, 850/1550 and 1310/1550) conversion.
The 1000FF support a constant data rate signal between 500Mbps to 1250Mbps allowing the converter to be used in Ethernet networks as well as other fiber-to-fiber protocol applications. Both ports operate at the same date rate.
iConverter 1000FF models support multimode and single-mode dual fiber; and single-mode single-fiber with SC connectors.
The 1000FF features user-selectable Link Propagate and Remote Fault Detection modes to facilitate quick fault detection, isolation, and reporting.
iConverter 1000FF media converters are available as compact, unmanaged standalone units, or
chassis plug-in modules that can be managed with a Management Module (NMM2) or Network Interface Device (NID) installed in the chassis. The management module provides access to all the advanced
features on the module.
VLAN-Switch und Ethernet-LWL-Konverter 100Base-Fx zu 100Base-Fx LWL
Der Managed-Medienkonverter iConverter 2Fx gehört zur modular aufgebauten iConverter-Produktfamilie. Der 2Fx ist eine kosten-günstige Lösung zur Erweiterung der Netzreichweite durch den Anschluss von Multimode-LWL-Netzgeräten über Single-Mode-LWL-Kabel. Der iConverter 2Fx regeneriert das fiberoptische Signal und taktet es neu. Zur Erweiterung der Netzreichweite können mehrere 2Fx benutzt werden.
100Base-Fx-LWL-Konverter
Die Managed-Medienkonverter iConverter 100FF gehören zur modu-lar aufgebauten iConverter-Produktfamilie. Der 100FF bietet Multi-mode zu Single-Mode-LWL-Konversion und ist eine kostengünstige Lösung zur Erweiterung der Netzreichweite durch den Anschluss von Multimode-LWL-Netzgeräten über Single-Mode-LWL-Kabel.
Der Managed-Medienkonverter iConverter OC3FF gehört zur modular aufgebauten
iConverter-Produktfamilie.
er OC3FF bietet eine Kon- version Multimode- zu Single-Mode-LWL und ist eine kostengünstige Lösung zur Erweiterung der OC-3-Netzreichweite durch den Anschluss von Multimode-LWL-Netzgeräten über
Single-Mode-LWL-Kabel.
Der Managed-Medienkonverter iConverter OC12FF gehört zur modular aufgebauten iConverter-Produktfamilie. Der OC12FF bietet eine Konversion Multimode- zu Single-Mode-LWL und ist eine kosten- günstige Lösung zur Erweiterung der Netzreichweite durch den Anschluss von Multimode-LWL-Netzgeräten über Single-Mode-LWL-Kabel.
