PT-PSE105GBSN-D-10 is a passive fiber to PoE converter.

It works with an input voltage of 50-57Vdc and operates under -40°C to +65°C.

It has a 10G SFP Interfaces and and the PoE output port delivers 48-55V/1.75A power up to 95W with 2.5G data rates.

PT-PSE105GWS-E Fiber PoE Media converter specially designed for complex industrial backhaul and networking applications, special scenarios, like highway side, exurb, etc. Enclosed in an IP40 high-impact metal case with DIN Rail mount bracket, but can work outdoor by covered with waterproof case.

After negotiating IEEE802.3bt standard PoE, the single PoE output port delivers 55Vdc, 1.1A up to 60W power with 6KV surge protection for remote PDs over 4 Pair at 10/100/1000Mbps data rates.  It works with a wide input voltage of 12-55Vdc make it possible for solar application and operates under -40℃ to +65℃. It fully complies with IEEE802.3bt and remains compatible with any IEEE802.3af/at compliant devices, such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks.

For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables.

PT-PSE105GBS-AC is an PoE Fiber Media Converter with PoE functionality that can be used as a PoE Injector offers a unique solution to powering long-range installations, where the data input comes over fiber, such as special scenarios, like highway side, exurb applications.Enclosed in an IP40 high-impact metal case but can work outdoor by being covered with a waterproof case.

After negotiating IEEE802.3bt standard PoE, the single PoE output port delivers 55Vdc, 1.1A up to 60W power with 6KV surge protection for remote PDs over 4 Pair at 10/100/1000Mbps data rates.  It works with a wide input voltage of 100-240VAC, 50 or 60 Hz or 44-57Vdc and operates under -40℃ to 65℃. It fully complies with IEEE802.3bt and remains compatible with any IEEE802.3af/at compliant devices, such as IP Cameras, wireless APs, Microwave radios, IoT applications, door locks, displays, POS, and information kiosks.

For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables. This model is equipped with a standard DIN rail mounting bracket, which can easily jam into the guide rail.

PT-PSE105GS-E  SFP PoE Media Converter specially designed for complex industrial backhaul and networking applications, special scenarios, like highway side, exurb, etc. Enclosed in an IP40 high-impact metal case with DIN Rail mount bracket, but can work outdoor by covered with waterproof case.

After negotiating IEEE802.3at standard PoE, the single PoE output port delivers 55Vdc, 0.55A up to 30W power with 6KV surge protection for remote PDs over 2 Pair at 1000Mbps data rates.  It works with a wide input voltage of 12-55Vdc make it possible for solar application and operates under -40℃ to +65℃. It fully complies with IEEE802.3at and remains compatible with any IEEE802.3af compliant devices, such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks.

For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables.

PT-PSE105GBLS-E is an industrial-rated media converter with PoE functionality that can be used as a PoE Injector offers a unique solution to powering long-range installations, where the data input comes over fiber, such as special scenarios, like highway side, exurb applications. Designed for the PoE++ powered 95W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks, SFP fiber Optical Slot supports 1000Base-FX.

Fully comply with PoE++ and remains compatible with any IEEE802.3bt/at/af compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non-PoE device.

Enclosed in an IP40 high-impact metal case with DIN-Rail mount bracket, designed for indoor use but can work outdoor by covered with waterproof case. It works with a wide input voltage of 12-55Vdc makes it possible for solar application and operates from -40℃ to +65℃,  For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables

PT-PSE105GS-AC is an indoor rated fiber PoE Media converter specially designed for complex industrial backhaul and networking applications, special scenarios, like highway side, exurb, etc. Enclosed in an IP40 high-impact metal case with DIN Rail mount bracket, but can work outdoor by covered with waterproof case.

After negotiating IEEE802.3at standard PoE, the single PoE output port delivers 55Vdc, 0.55A up to 30W power with 6KV surge protection for remote PDs over 2 Pair at 1000Mbps data rates.  It works with a wide input voltage of 100-240Vac or 44-57Vdc and operates under -40℃ to +65℃. It fully complies with IEEE802.3at and remains compatible with any IEEE802.3af compliant devices, such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks.

For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables.

PT-PSE105GS-D is a single port fiber PoE Media converter with 2 Pair PoE up to 30 watts of power with 6Kv surge protection

Designed for the PoE+ powered 30W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks. It supports 1000Mbps of data rates. Fully comply with IEEE802.3at and remains compatible with any IEEE802.3af compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non PoE device.

Enclosed in an IP40 high-impact metal case with DIN Rail mount bracket, designed for indoor use but can work outdoor by covered with waterproof case. It works with a wide input voltage of 44-55Vdc, the output voltage follows input and operates under -40℃ to +65℃,  For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables. It is suitable for special scenarios, like highway side, exurb, etc.

PT-PSE105GBS-E is an industrial-rated media converter with PoE functionality that can be used as a PoE Injector offers a unique solution to powering long-range installations, where the data input comes over fiber, such as special scenarios, like highway side, exurb applications. Designed for the IEEE802.3bt powered 95W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks, SFP fiber Optical Slot supports 1000Base-FX.

Fully comply with IEEE802.3bt and remains compatible with any IEEE802.3bt/at/af compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non-PoE device.

Enclosed in an IP40 high-impact metal case with DIN-Rail mount bracket, designed for indoor use but can work outdoor by covered with waterproof case. It works with a wide input voltage of 12-55Vdc makes it possible for solar application and operates from -40℃ to +65℃,  For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables.

PT-PSE105GBS-D is a single port fiber PoE Media converter with 4 Pair PoE up to 95 watts of power with 6Kv surge protection

Designed for the BT 95W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks, SFP fiber Optical Slot supports 1000Base-FX. Fully comply with IEEE802.3bt and remains compatible with any IEEE802.3af/at compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non PoE device.

Enclosed in an IP40 high-impact metal case with DIN Rail mount bracket, designed for indoor use but can work outdoor by covered with waterproof case. It works with a wide input voltage of 50-57Vdc, the output voltage follows input and operates under -40℃ to +65℃,  For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables. It is suitable for special scenarios, like highway side, exurb, etc.

PT-PSE105GWS-D is a DIN Rail SFP PoE Media Converter with 4 Pair power up to 60 watts  44-57 VDC

Designed for the BT powered 60W PoE Powered Devices (PDs), such as wireless access points, network cameras, VoIp phones, Base station, Microwave radio and other high power Ethernet terminals. It supports 1000Mbps of data rates. It is also compatible and safe to use with any IEEE802.3af/at compliant terminals. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non PoE device.

Enclosed in an IP40 fire retardant metal case, designed for indoor use but can work outdoor by covered with waterproof case with a Din-rail mount bracket. It operates with the input voltage of 44-57 VDC.

PT-PSE105GWS-AC is an indoor rated fiber PoE Media converter specially designed for complex industrial backhaul and networking applications, special scenarios, like highway side, exurb, etc. Enclosed in an IP40 high-impact metal case with DIN Rail mount bracket, but can work outdoor by covered with waterproof case.

After negotiating IEEE802.3bt standard PoE, the single PoE output port delivers 55Vdc, 1.1A up to 60W power with 6KV surge protection for remote PDs over 4 Pair at 10/100/1000Mbps data rates.  It works with a wide input voltage of 100-240Vac or 44-57Vdc and operates under -40℃ to +65℃. It fully complies with IEEE802.3bt and remains compatible with any IEEE802.3af/at compliant devices, such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks.

For planning purposes, the effective distance is 100 meters over Cat5e/Cat6 cables.
