PT-PD208GT is a single-port PoE splitter with a high-impact metal shell. It works as a converter separating power and data from the PoE source and then delivering power and data to non-PoE devices. DIP switch for 12V and 24V adjustable output voltage. Working for 25W non-PoE PDs, such as power communication stations, wireless APs, network cameras, and other non-PoE terminals. Supporting 10/100/1000Mbps of data speed.It is powered by IEEE802.3at standard PSE or PoE+ Switch at 30W. The effective distance is 100 meters over Cat5e/Cat6 cables from data source to terminal device. Isolated design inside to avoid high current input damage. The model is easy to install with two mounting holes.

It is powered by IEEE802.3at standard PSE or PoE+ Switch at 30W. The effective distance is 100 meters over Cat5e/Cat6 cables from data source to terminal device. Isolated design inside to avoid high current input damage. The model is easy to install with two mounting holes.

PTD-AF-5V PoE to DC 5V Splitter with 4 Pair PoE up to 12.5 watts of power at 5VDC


It works as a converter separating power and data from PoE injector and delivering power and data to non-PoE devices. It supports 10/100Mbps of data speed. It works for 12.5W non-PoE PDs, such as high power communication station, wireless APs, network cameras and other non-PoE terminals. It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 93%.

Enclosed in a high-impact metal shell, designed for indoor installation. It operates with input voltage of 40-57 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables. The model is easy to install with four mounting holes.

PTD-AF-12V PoE to DC 12V Splitter with 4 Pair PoE up to 12 watts of power at 12VDC


It works as a converter separating power and data from PoE injector and delivering power and data to non-PoE devices. It supports 10/100/1000Mbps of data speed. It works for 12W non-PoE PDs, such as high power communication station, wireless APs, network cameras and other non-PoE terminals. It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 93%.

Enclosed in a high-impact metal shell, designed for indoor installation. It operates with input voltage of 40-57 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables. The model is easy to install with four mounting holes.

PT-PD208GMO-5/12/24,  IEEE802.3 at PoE splitter with  isolated design. It works for 20/25.8/25.2W non-PoE PDs, such as network phone, wireless AP, network camera ONU (Optical Network Unit).

Its output power is 5Vdc 4A or 12Vdc 2.15A or 24Vdc 1.05A. It supports 10/100/1000Mbps of data speed. The power pin: 4/5(+), 7/8(-) .It is an isolated design inside to avoid high current input damage.

PT-PD208GMO-5/12/24 is designed for indoor use with matel shell. It works with input voltage of 40-57Vdc from PoE injector and operates under -40℃ to 65 ℃. The effective distance is 100 meters over Cat5e/Cat6 cables. The model is small in size and easy to install with four mounting holes.

PT-PD208GBHO-12 is a single port splitter with 4 Pair PoE up to 60 watts of power at 55 VDC


It works as a converter separating power and data from PoE injector and delivering power and data to non-PoE devices. It supports 10/100/1000Mbps of data speed. It works for 60W non-PoE PDs, such as high power communication stations, wireless APs, network cameras and other non-PoE terminals. It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 93%.

Enclosed in a high-impact metal shell, designed for indoor installation. It operates with input voltage of 40-57 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables. The model is easy to install with four mounting holes.

PT-PD208G-12,  IEEE802.3af PoE splitter. It works for 18W non-PoE PDs, such as network phone, wireless AP, network camera ONU (Optical Network Unit).

Its output power is 12Vdc 1.5A. It supports 10/100/1000Mbps of data speed. The power pin: 4/5(+), 7/8(-) or 3/6(+),1/2(-)

PT-PD208G-12 is designed for indoor use. It works with input voltage of 36-57Vdc from PoE injector. The effective distance is 100 meters over Cat5e/Cat6 cables. The model is small in size and easy to install with two mounting holes.

PT-PD208GBO-12 is a single port splitter with 4 Pair PoE up to 60 watts of power at 55 VDC


It works as a converter separating power and data from the PoE injector and delivering power and data to non-PoE devices. It supports 10/100/1000Mbps of data speed. It works for 60W non-PoE PDs, such as high power communication stations, wireless APs, network cameras, and other non-PoE terminals. It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 93%.

Enclosed in a high-impact metal shell, designed for indoor installation. It operates with input voltage of 40-57 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables. The model is easy to install with four mounting holes.

PT-PD208GB-5/12/24 is a single port splitter with 4 Pair PoE up to 60 watts of power at 55 VDC.

It works as a converter separating power and data from PoE injector and delivering power and data to non-PoE devices.It supports 10/100/1000Mbps of data speed. It works for 60W non-PoE PDs, such as high power communication station, wireless APs, network cameras and other non-PoE terminals. It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 93%.

Enclosed in a high-impact metal shell, designed for indoor installation. It operates with input voltage of 40-57 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables.The model is easy to install with four mounting holes.

PT-PD208GMO-12, IEEE802.3at PoE splitter with  isolated design. It works for 25.8 non-PoE PDs, such as network phone, wireless AP, network camera ONU (Optical Network Unit).


Its output power is 12Vdc 2.15A. It supports 10/100/1000Mbps of data speed. The power pin: 4/5(+), 7/8(-). It is an isolated design inside to avoid high current input damage.

PT-PD208GMO-12 is designed for indoor use with a metal shell. It works with input voltage of 40-57Vdc from PoE injector and operates from -40℃ to 65 ℃. The effective distance is 100 meters over Cat5e/Cat6 cables. The model is small in size and easy to install with four mounting holes.

PT-PD208GBO-5/12/24 is a single port splitter with 4 Pair PoE up to 60 watts of power at 55 VDC

It works as a converter separating power and data from PoE injector and delivering power and data to non-PoE devices.It supports 10/100/1000Mbps of data speed. It works for 60W non-PoE PDs, such as high power communication station, wireless APs, network cameras and other non-PoE terminals. It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 93%.

Enclosed in a high-impact metal shell, designed for indoor installation. It operates with input voltage of 40-57 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables.The model is easy to install with four mounting holes.

PTD-AF-5V PoE to DC 5V Splitter with 4 Pair PoE up to 12.5 watts of power at 5VDC


It works as a converter separating power and data from PoE injector and delivering power and data to non-PoE devices. It supports 10/100Mbps of data speed. It works for 12.5W non-PoE PDs, such as high power communication station, wireless APs, network cameras and other non-PoE terminals. It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 93%.

Enclosed in a high-impact metal shell, designed for indoor installation. It operates with input voltage of 40-57 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables. The model is easy to install with four mounting holes.

PT-PD208GM-5/9/12/24,  IEEE802.3 at PoE splitter with  isolated design. It works for 20/22.5/25.8/25.2W non-PoE PDs, such as network phone, wireless AP, network camera ONU (Optical Network Unit).

Its output power is 5Vdc 4A or 9Vdc 2.5A or 12Vdc 2.15A or 24Vdc 1.05A. It supports 10/100/1000Mbps of data speed. The power pin: 4/5(+), 7/8(-) .It is an isolated design inside to avoid high current input damage.

PT-PD208GM-5/9/12/24 is designed for indoor use with matel shell. It works with input voltage of 40-57Vdc from PoE injector. The effective distance is 100 meters over Cat5e/Cat6 cables. The model is small in size and easy to install with four mounting holes.

PT-PD208GBH-5/12/24 is a single port splitter with 4 Pair PoE up to 95 watts of power at 55 VDC .

It works as a converter separating power and data from PoE injector and delivering power and data to non-PoE devices.It supports 10/100/1000Mbps of data speed. It works for 95W non-PoE PDs, such as high power communication station, wireless APs, network cameras and other non-PoE terminals. It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 93%.

Enclosed in a high-impact metal shell, designed for indoor installation. It operates with input voltage of 40-57 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables. The model is easy to install with four mounting holes.

PT-PD208GBHO brings the power of PoE++ to a single port PoE splitter with high-impact metal case. It takes 95W power and data from PoE injector or switch, and delivers power and data to non-PoE devices. It outputs power 5Vdc/12Vdc/24Vdc(optional) and supports 10/100/1000Mbps of data rates. It is capable of powering 82.5 watt non-PoE Powered Devices (PD’s), such as wireless APs, network cameras, digital signage, LED Lighting and other high power non-PoE terminals.

Designed for indoor use, it works with an input voltage range of 40-57Vdc and operates under -40℃ to +65 ℃. The effective distance is 100 meters over Cat5e/Cat6 cables.

It is an isolated design inside to avoid high current input damage. Innovative technology increase energy-efficient up to 94%. The wall mounting case and screw terminal connectors make this device easy to deploy
